30gal 40gal 50 gallons stainless steel electric water heater tank domestic central heating tank
| Capacity | L | 100 | 200 | 300 | 400 | 500 | 600 | 800 | 1000 |
| Inner tank diameter | mm | Φ370 | Φ470 | Φ500 | Φ550 | Φ600 | Φ650 | Φ700 | Φ800 |
| Out shell diameter | mm | Φ470 | Φ560 | Φ600 | Φ650 | Φ700 | Φ760 | Φ800 | Φ900 |
| Inner tank material | mm | SUS304 / SUS316L / Duplex2205 / Duplex2304 | |||||||
| Out shell material | mm | galvanized steel with painting / stainless stell / PU | |||||||
| Out shell color | white / silver-grey / blue /red / golden / stainless stell | ||||||||
| Max.working pressure | bar | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
| Max.testing pressure | bar | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 |
| Max.running temperature | ℃ | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 |
| Heating loss | W/K | 0.65 | 0.72 | 0.89 | 1.02 | 1.15 | 1.26 | —— | —— |
| Standing loss | W | 30 | 33 | 40 | 46 | 52 | 57 | —— | —— |
| ERP Class | A | A | A | A | A | A | A | A | |
| Electrical heater | kw | 1.5 | 1.5 | 1.5 | 1.5 | 3 | 3 | 3 | 3 |
| Mg.Anode | mm | Φ22*300 | |||||||
| Water connection | G / BSP / NPT 3/4" | G / BSP / NPT 1" | |||||||
| Packing size | mm | L:540 W;540 H:117 | L:630 W:630 H:1440 | L:670 W:670 H:163 | L:720 W:720 H:1920 | L:780 W:780 H:1930 | L:850 W:850 H:1940 | Φ900*2200 | Φ980*2420 |
Q1. Material?
For inner tank we have SUS304,SUS316L and Duplex 2205. The most popular is Duplex 2205. For the outer shell is galvanize with painting and stainless steel both are available.Also for the big tank we can do the PU coat.
Q2.Volume?
For now we can do from 20L to 1000L.
Q3. Lead time?
For the LCL order is 15 days after received the payment . for the container order is 25 days after received the advance payment.
SST
You covered with their 100L, 150L, and 200L force electric heater water tanks with regards to having warm water in your house or company, the brand name has. These tanks are made to final, as a result of their construction is durable and materials.
with one of these, you might never need to worry about operating away from heated water once more. The SST truly are made to quickly heat up and keep a regular heat, you'll need it in order to enjoy warm water whenever. and, using their stress design, you are going to enjoy stronger water movement than by having a tank is standard.
These tanks are user friendly. Merely plug them in and allow them to do their thing. They are additionally compact sufficient to squeeze in many spaces, and that means you do not have to be concerned about locating a committed spot for them.
One of many standout features of these water tanks is the durability. They are created from top-quality materials that can withstand the damage of everyday usage, in order to enjoy water is hot years into the future. and, along with their stress design, they truly are less inclined to leak or breakdown as time passes.
Not only is it durable, these tanks are energy-efficient. They are made to utilize only a small amount power that you can, in order to enjoy water is hot worrying all about high power bills. They truly are additionally green, making them an option is very good anybody seeking to reduce their carbon impact.
Why wait? Invest in a SST water tank today and commence enjoying heated water if you want it.
